Hinge jig Skeleton two part in case

The two part Contractor Hinge Jig is a portable fully adjustable block template set designed for recessing hinges in wooden doors & frames using a plunge router.|It is easy to use with minimal setting-up time, completing the job both accurately & quickly.|Used on-site & in joinery shops to increase productivity with excellent results. |Fully adjustable apertures for fire door requirements and renovation work.|Can be used on both inside and outside doors, rebated frames and on maximum 25mm thick fixed stops.|Ideal for fitting a new door in an old frame.|No need for marking out in the conventional way. |Quick & simple to set-up as the hinge is used as the pattern.|Clean & accurate recesses are achieved every time. Suitable for timber based doors & square butt hinges.|Use with a light duty plunge router with 1/4 inch collet.|Long reach router cutter required, 12mm diameter with 70mm overall length.|Adjustable edge guides with preset for hinge of 20mm, 25mm and 30mm|Unibase may be needed.|Patent No. GB2490139|T4EK router requires a ref. UNIBASE or special guide bush ref. GB/T4/160.
